OFFER#

TERRIER APC

TYPE:	APC
DESCRIPTION:	Terrier APC
PRICE:	Upon Request
PACKING:	Ex-Works

TERRIER APC

From new manufacture

Subject unsold or market withdrawa

CEN LEVEL BR6

Making better protection more affordable, the Terrier LT-79 is a versatile vehicle with high-powered rifle round protection. Oﬀering user-friendly features for both oﬀensive and defensive situations this vehicle ideal for law enforcement The Terrier LT-79 has been rigorously tested to ensure its performance exceeds expectations. Some of its standout features include 60% grade-ability, 700mm fording depth 30% side slope and 700mm trench crossing.

BASE SPECIFICATIONS

ENGINE TYPE: 4.5L V8 Turbo-diesel (195hp) Toyota

TRANSMISSION TYPE: 5-Speed Manual

MAXIMUM TORQUE: 430 Nm @ 1200 - 3200 rpm

POWER: 145 kW (195hp)

MAX SPEED: 100 km/h

CRUISING RANGE: 800 km

BRAKE TYPE Ventilated 6 Piston Disc Brakes /

(FRONT/REAR): 4 Piston Disc Brakes

FUEL TANK CAPACITY: 2 x 90 Liters

CURB WEIGHT: 5100 kg (Standard Equipment & Protection)

PAYLOAD: 1000 kg

SEATING: 2 + 6

DOORS: 3

ROOF TURRET WITH HATCH OPTIONAL

Heavy duty suspensions, axles, category leading ground clearance and independent cooling systems are just some of the features that increase the vehicle’s utility and usability. The Terrier LT-79 was designed to offer law enforcement teams a highly armored vehicle that stays within budget.

A unique Thought Design Process offers a choice of over forty customization options, ensuring that all our vehicles come with maximum flexibility. This process allows us to reduce both cost and production time, and lets us deliver a vehicle suited to your exact needs.

RUNNING GEAR

Drive-line Selectable 4x4

Steering LHD / RHD, Hydraulically Assisted

Suspension Front – coil springs with hydraulic shock absorbers

Rear – leaf springs with hydraulic shock absorbers

Rims 8.5 x 17” steel wheels

Tires 285/75 R17

Run Flats Standard

STIS Optional

Brakes Ventilated Disc, Rear Drum Brakes

MOBILITY

Max Speed 100 km/h

Turning Circle 14.4 m

Fuel Range 800 km

Grade-ability 70%

Static Side Slope 20%

Vertical Step 300 mm

Trench Crossing 600 mm

Fording Depth 600 mm

Approach Angle 43°

Departure Angle 36°

Specification and photos are not contractual and are subject to verification upon inspection
