ELECTRIC CAR OMEGA





TYPE:

Car

DESCRIPTION:

Electric Car Omega

PRICE:

Upon Request

PACKING:

Ex Works






electric car omega



From New Manufacture





If we can find very powerful & experienced agent in EU.



We will apply EEC.



See below the details of three models for your reference.

Plz choose suitable model according to your market

No Europe or USA at this stage but vehicle can be certified IF order large enough



Omega E200

Omega E100

New e-power car omega

Omega



Basic specification Model E200
Body material Steel
L×W×H(mm) 3100*1400*1480
Tread (front and back)（mm） 1220/1250
Wheel base(mm) 2000
Weight(Kg) 700
 distance per charge（km） 120
Maximum Speed 45
Maximum Climbing Grade 30%
Minimum ground clearance (mm) 140
The number of approved load 4
Motor type 3kw
Storeage Battery Model 120Ah/12V/Lead-acid free maintenance
 Battery Quantity 5
Charging Voltage 60
Wheel hub AL
Tyre 145/70R12
Rated engine speed 2800rpm
Max engine speed 5600rpm
Front/Rear Brake Front ventilated disc/rear drum
Steering system wheel gear power
Suspension system Spiral spring integral front axle
Car colour rId2
Red  Yellow  Blue  White
rId1rId4rId3

Basic specification Model E200
Body material Steel
L×W×H(mm) 3100*1400*1480
Tread (front and back)（mm） 1220/1250
Wheel base(mm) 2000
Weight(Kg) 700
 distance per charge（km） 120
Maximum Speed 45
Maximum Climbing Grade 30%
Minimum ground clearance (mm) 140
The number of approved load 4
Motor type 3kw
Storeage Battery Model 120Ah/12V/Lead-acid free maintenance
 Battery Quantity 5
Charging Voltage 60
Wheel hub AL
Tyre 145/70R12
Rated engine speed 2800rpm
Max engine speed 5600rpm
Front/Rear Brake Front ventilated disc/rear drum
Steering system wheel gear power
Suspension system Spiral spring integral front axle
Car colour rId2
Red  Yellow  Blue  White
rId1rId4rId3




Model

  Economy Extended-Range Electric Vehicle plus petrol engine Standard Luxury Sport
Technical data
Performance   Parameter   Length×width×height (mm)  3520×1570×1490
Wheel base(mm)  2345
Tread(front/rear)(mm)  1330/1310
Minimum  turning radius(m)  ≤5
Ground Clearance   (full load)(mm)  145
Seating 4
Total weight(kg)  980 940 1070 1040 1000
Maximum speed(km/h) 43 45 50 70 70
Maximum Grade ability（%）  30 30 30 30 30
Power consumption(Kwh/100km)  8 9 8 9 12
Economic speed(km/h)  35 35 40 40 48
Motor Model  DC permanent magnet 48V 4KW DC permanent magnet 48V 4KW DC permanent magnet 60V 5KW AC asynchronous 72V7.5KW AC asynchronous 72V7.5KW
Battery  Specification  6V200Ah×8 maintainable
Battery 		 8V150Ah×6 Gel mmaintenance free 6V200Ah×10 Gel maintenance free/Lead carbon battery 8V150Ah×9 Gel maintenance free/Lead carbon battery 6V160Ah×12        Bipolar battery
Battery charger specification  48V25A  48V25A  60V30A  72V30A  72V30A or          Charging station
Tires type 155/65R13 77S  155/65R13 77S  155/65R13 77S 155/65R13 77S 155/65R13 77S
Drive form Rear driving Front driving Front driving Front driving Front driving
                            Vehicle configuration Fully enclosed charger ○  ○  ●  ●  ●
EPS electric power steering system ○  ○  ●  ●  ●
17 inch Alloy Wheels ●  ●  ●  ●  ●
17 inch Steel Wheels  ○  ○  ○  ○  ○
The front window galss electric lift ●  ●  ●  ●  ●
Senior cloth seats  -  -  ●  ●  ●
Ordinary seats ●  ●  -  -  -
Luxury interior ●  ●  ●  ●  ●
Electronic vacuum brake booster ●  ●  ●  ●  ●
Rear fog lamp ○  ○  ○  ○  ○
Heating system  ●  ●  ●  ●  ●
Air-condition -  -  ○  ○  ○
Central Power Lock -  -  ○  ○  ○
Back Row Bi-touch safety belt  ○  ○  ○  ○  ○
Driver's side sun visor with aper clip  ●  ●  ●  ●  ●
Copilot side sun visor with mirror -  -  ●  ●  ●
Spare type ○  ○  ○  ○  ○
GPS Map ○  ○  ○  ○  ○
Extend range Dynamo - ●  -  -  -
Fast charging device -  -  -  -  -
Note：●With Configuration， ○ Optional Configuration，  - Not Available。




Standard Luxury
Basic Specifications L×W×H(mm) 3815*1648*1530
Wheel base(mm) 2340
Front/Rear tread(mm) 1420/1410
Weight(Kg) 1200kg 1180kg
Battery Model Gel lead acid battery Gel lead acid battery
Battery Size 6V200Ah×10  8V150Ah×9
Rated Motor Model 5KW DC 7.5KW(Brushless ac asynchronous)
Maximum Speed 50km/h 70km/h
Maximum  Gradeability 30%
Body Structure All metal monocoque body overall structure
Suspension System Before: McPherson independent suspension (with auxiliary frame) after: torsion beam, coil spring type independent suspension
Front/Rear Brake Front ventilated disc/rear drum + double line + vacuum booster
Speed control system Electronic shift stepless variable speed
Steering system Electronic steering power
Tyre 175/65 R14
External equipments The case full size spare tire ○ ○
The roof rack ● ●
Before the combination of crystalline light ● ●
Side turn signal ● ●
Body with folding color of rearview mirror ● ●
Four rubbing strip ● ●
Electric adjustment outside rearview mirror ● ●
Interior equipments  Black instrument desk ● ●
Injection forming interior trim panels ● ●
Double color four sports steering wheel ● ●
Multi-functional combination instrument ● ●
Electric heater ● ●
Manual Air Conditioning  ○ ○
Four electric Windows ● ●
Remote control door lock ● ●
Angle adjustable steering column ● ●
Remote control device open the back door ● ●
The radio with a AUX interface ● ●
Double color knit sports seats ● ●
security equipment  The front three point safety belt ● ●
Not Available a seatbelt warning device ● ●
Not shut the door alarm equipment system ● ●
Steering lock anti-theft device ● ●
Overspeed alarm device ● ●
Child safety door look ● ●
Four door anticollision beam profile ● ●
Rear spoiler (with high brake lights) ● ●
The dazzle eye in the rearview mirror ● ●
Note：●With Configuration， ○ Optional
Configuration，  - Not Available。





Specification and photos are not contractual and are subject to verification upon inspection
