OFFER#

DRAGON 8X8

TYPE:	Vehicle
DESCRIPTION:	Dragon 8x8
PRICE:	Upon Request
PACKING:	Ew-Works

dragon 8x8

From New manufacture

MODEL No. Dragon's 8x8 Panther

(MOQ: 1X20’GP)

ENGINE   812cc,4 Strokes,Liquid-cooled, Three cylinder

MAX.POWER(KW/rpm) 57.1hp/6000rpm

MAX.TORQUE(NM/rpm) 76N.M/3500~4000rpm

BORE STROKE 66.5mm x 72mm

STEERING One-piece ergonomic handlebar steering control with mounted brake lever.

CONTROLS Right-hand twist grip throttle grip and dash-mounted choke
       control. Light switch and ignition switch.

GROUND CLEARANCE 203mm

COMPRESSION RATIO 9.5:1

Frame Formed steel channel construction, welded for high strength and durability.

Body Fiberglass-Reinforced Plastics.

SEATING CAPACITY common 4 passengers, max to 6 passengers

CLUTCH Belt-driven, Continuously Variable Transmission (CVT)
     maximizes engine power to the transmission.

STARTING Electric Start

DRIVE SYSTEM Roller chains drive machined sprockets that are spline
      -fit onto axles. Bearings are greasable.

GEARSHIFT By Hand

TRANSMISSION differential steering transmission
       with dedicated Hi and Low selector; Forward, Neutral, Reverse.

BRAKE Hydraulic

MAX.SPEED 45KM/h on land/ 4km/h on water

FUEL CAPACITY 35L

COLOR Commonly green,also could be red,blue,black,yellow and camouflage

TIRE 24x11-10

PRODUCT SIZE 2850x1500x1100mm

OPERATING CONDITIONS All weather, all terrain, -40C to +40C

GROSS/NET WEIGHT 700/600kg

QUANTITY OF LOADING Qty/20’GP:4PCS - Qty/40’GP:8PCS

Specification and photos are not contractual and are subject to verification upon inspection

PLEASE BE ADVISED THAT INFORMATION INCLUDED IS CONFIDENTIAL IN NATURE AND IS BASED ON PRE-EXISTING BUSINESS RELATIONSHIP WITH THE LEGAL OWNER OF PROPERTY DESCRIBED HEREIN (IF APPLICABLE). AS SUCH, UPON RECEIPT OF SAID INFORMATION THE RECEIVER ACKNOWLEDGES THAT ANY UNAUTHORIZED CONTACT WITH SAID LEGAL SELLER WILL BE CHARACTERIZED AS A BREACH OF CONFIDENTIALITY AND SAID AGREEMENT MAY BE ENFORCED UNDER EXISTING LAW OR IN EQUITY.

This paper was prepared by General Equipment Inc.
The paper represents an offer of a partner of General Equipment Inc.
All rights are reserved by and for General Equipment Inc.
All content and ideas of this paper are the property of General Equipment Inc.

MODEL No.	Dragon's 8x8 Panther
	(MOQ: 1X20’GP)

ENGINE	812cc,4 Strokes,Liquid-cooled, Three cylinder
MAX.POWER(KW/rpm)	57.1hp/6000rpm
MAX.TORQUE(NM/rpm)	76N.M/3500~4000rpm
BORE STROKE	66.5mm x 72mm
STEERING	One-piece ergonomic handlebar steering control with mounted brake lever.
CONTROLS	Right-hand twist grip throttle grip and dash-mounted choke control. Light switch and ignition switch.
GROUND CLEARANCE	203mm
COMPRESSION RATIO	9.5:1
Frame	Formed steel channel construction, welded for high strength and durability.
Body	Fiberglass-Reinforced Plastics.
SEATING CAPACITY	common 4 passengers, max to 6 passengers
CLUTCH	Belt-driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission.
STARTING	Electric Start
DRIVE SYSTEM	Roller chains drive machined sprockets that are spline -fit onto axles. Bearings are greasable.
GEARSHIFT	By Hand
TRANSMISSION	differential steering transmission with dedicated Hi and Low selector; Forward, Neutral, Reverse.
BRAKE	Hydraulic
MAX.SPEED	45KM/h on land/ 4km/h on water
FUEL CAPACITY	35L
COLOR	Commonly green,also could be red,blue,black,yellow and camouflage
TIRE	24x11-10
PRODUCT SIZE	2850x1500x1100mm
OPERATING CONDITIONS	All weather, all terrain, -40C to +40C
GROSS/NET WEIGHT	700/600kg
QUANTITY OF LOADING	Qty/20’GP:4PCS - Qty/40’GP:8PCS

GENERAL EQUIPMENT INC.
