GENERAL   EQUIPMENT   INC.

Dimension

Overall length（mm）

8980

Engine

Model

YC6J190 20

Overall width（mm）

2400

Manufacturer

YUCHAI

Overall height（mm）

3100

Position

Rear mounted

Wheel base（mm）

4500

Type

Direct injection, pressurized, mid-cooling

Rated max. mass（Kg）

11500

Max. power（ Kw/ps）

132/190

Seat capacity

40+1

Max. Torque (N.m/rpm)

660/1300-1500

Fuel

Diesel oil

Max. Speed (km/h)

90

Exhaust standard

Euro II

Item

Basic configuration

Chassis

Chassis

Zhongda Yanjing YJ6830

Transmission

Five speed

Front  axle

“工” section

Rear  axle

Unitary，single reduced

Suspension

Multiple-leaf spring

Steering

Hydraulic power steering

Brake

Service brake

Drum type dual-circuit air brake

Parking brake

Power storage spring parking brake

Fuel tank

120L

Tyre

8.25R20 meridian tyre

Other

Luxury stainless steel wheel cap, running recorder

Main assembly of body

Body structure

rectangle steel tube welding，whole phosphating

Interior trimming

common inner trimming

Door& door pump

Front single rear double in-swing door

Window& glass

Enclosed side windows, panoramic compressed front windshield

Safety ceiling window & door

One safety scuttle, electric ventilation fan

Rear system

Manual luxury reversing mirror, interior mirror

Video system

AM/FM cassette recorder

Seats

Polished surface seats

Lights

Unitary Front/Rear grouped Lights

Painting

Domestic fine paint

Others

Plastic coating handrail, speaker, fire extinguisher, driver’s sunshade curtain, anti-slide floor leather, front and rear simple line plates with lamp house, fan

 Warrantee:

within one year and/or 30000km.
