OFFER#

250CC ATV

TYPE:	ATV
DESCRIPTION:	250cc ATV Quad
PRICE:	Upon Request
PACKING:	Ex Works

250cc atv quad

From New Manufacture

EEC 250CC ATV QUAD

ROAD DRAGON

Good Stability.. High Speed.

COOL Design.

1. engine type :250CC,4-stroke, Water Cooled.
2. max torque : 18.5Nm/4500rpm
3. max power :12.5kw/7500rpm
4. ignition type :CDI
5. transmission :Manual
6. brake (Front/Rear):Disc /Disc
7. starting system :Electric start
8. battery spec :12V,9AH
9. front suspension details :double A x swing arm, air chamber shock absorbers
10. rear suspension details :inner ballonet absorber
11. front tire spec : 185/30 - 14 rear tires spec : 235 /30 - 14
12. vehicle dimensions :203x 130x 100cm
13. wheel base :138cm
14. seat height from ground :95cm
15. ground clearance :110mm
16. load capacity :200kg
17. fuel tank capacity :17L
18. gross weight in carton :230kg
19. net weight :200kg
20. packing size:180x 74 x 81cm
21. max. speed: 95km/h
Capacity:

Qty/20' GP: 18 units
Qty/40' HQ: 54 units

Specification and photos are not contractual and are subject to verification upon inspection
