2000 KVA
|
TYPE: |
Genset |
|
DESCRIPTION: |
2000 KVa Genset |
|
PRICE: |
Upon Request |
|
PACKING: |
Ex-Depot |
CAT 2000 KVA GENSET
Subject unsold or market withdrawal
|
3 x 2000 kW CAT make Containerised GEGs for sale.
These sets can be inspected on foundation in India after signing of NCND agreement. 3 Nos. - 2000 kW each, CATERPILLAR (2008) make Gas Engine Generator Sets,
having the following technical specifications:
TECHNICAL SPECIFICATIONS: |
| ENGINE | |||
| DETAILS | ENGINE 1 | ENGINE 2 | ENGINE 3 |
| Make | Caterpillar | Caterpillar | Caterpillar |
| Year of Make | 2008 | 2008 | 2008 |
| Model | G3520 E | G3520E | G3520E |
| Output | 2000 kW/2776 HP | 2000 kW/2776 HP | 2000 kW/2776 HP |
| Speed | 1500 RPM | 1500 RPM | 1500 RPM |
| Year of Commissioning | 2011 | 2011 | 2011 |
| GENERATOR | |||
| DETAILS | GENERATOR 1 | GENERATOR 2 | GENERATOR 3 |
| Make | Caterpillar | Caterpillar | Caterpillar |
| Year of Make | 2008 | 2008 | 2010 |
| Frame | 2650 | 2650 | 2650 |
| Model | SR4B HV | SR4B HV | SR4B HV |
| Output | 2500 kVA/2000 kW | 2500 kVA/2000 kW | 2500 kVA/2000 kW |
| Speed | 1500 RPM | 1500 RPM | 1500 RPM |
| Volts | 10500 | 10500 | 11000 |
| AMPS | 138 | 138 | 131 |
| No. of Phase | 3 | 3 | 3 |
| Frequency | 50 Hz | 50 Hz | 50 Hz |
| P. F | 0.8 | 0.8 | 0.8 |
| Insulation Class | F | F | H |
| Altitude | 1000 M | 1000 M | 1000 M |
| Excitation | 63 Volts | 63 Volts | 52 Volts |
| 13.8 AMPS | 13.8 AMPS | 11.4 AMPS | |
OPERATING HISTORY:
| Engines | Total Running Hours |
| Engine 1 | 22,436 hours |
| Engine 2 | 31,297 hours |
| Engine 3 | 28,617 hours |
SCOPE OF SUPPLY:
| PLANT & MACHINERY: 3 X 2 MW = 6 MW CATERPILLAR | ||
| Sr .No. | Name of the Equipment | Qty |
| 1. | Caterpillar Gas Genset-3520e Model | 3 |
| 2. | Terberg Engine Control Panel | 3 |
| 3. | Common Chimney+ Cooling Systems+ Cables+ Trays | 1 Lot |
| 4. | Radiator Structure | 3 |
| 5. | Acoustic Enclosure | 3 |
| 6. | 11 KV Switchgear/NGR And AUX MCC Panels | 1 Lot |
| 7. | Gas Flow Meter + Starting Batteries | 1 set |
Specification and photos are not contractual and are subject to verification upon inspection
