BTR-3





TYPE:

APC

DESCRIPTION:

BTR-3 APC

PRICE:

Upon Request

PACKING:

Ex-Works





BTR-3 APC



Subject unsold or market withdrawal





Description

Value

Type: Armored Amphibious All-Wheel Drive

Weight:

·         with small arms protection

15.4 ton

·         with additional larger caliber protection

≤ 25 ton

Configuration

8x8

Crew

Commander, gunner, driver

Troop capacity

≤ 6 (Depending on configuration)

Length:

7.650M

Width:

2.900M

Height:

2.860M

Power-to-weight ratio:

·         with small arms protection

≥ 28.6 hp/ton

·         with additional larger caliber protection

≥ 20 hp/ton

Maximum speed:

·         on road

85 km/hr (53 mph)

·         in water

≤ 8 km/hr (5 mph)

Cruising range

600 km (373 miles)

Gradient

30 degrees

Vertical Obstacle

0.5M

Side slope

25 degrees

Trench Obstacle

2M

Operatinal Temperature

-15 to +55 Centigrade

Air Conditioning System

Webasto C6

Filter-ventilator unit

(available)

Heaters

Air Heaters

Fire Suppressions System

Automatic: Double-Action om Powerpack Compartment

Engine:

Type

Diesel

Power output

326 hp

Make and Model

DEUTZ BF6M1015

Transmission

Allison MD3066 Fully-Automatic

Turret

One man Stabilized

Armament

(Varies according to configuration)






Specification and photos are not contractual and are subject to verification upon inspection
