IGLA-S man-portable air defence missile system

Purpose: the system is designed to engage front line aircraft, helicopters, cruise missiles and UAVs under direct visibility conditions and in the night time, head-on and tail chase, in background clutter and thermal countermeasures environment.

IGLA-S MANPADS is a new-generation system featuring considerably extended firing range and enhanced kill probability against aerial targets and possessing a new quality for this class of systems - high engagement effectiveness against small-size targets like cruise missiles and UAVs.

Main features of IGLA-S system:

•         enhanced kill probability against aerial targets and increased warhead lethality due to:

◦         increased HE quantity (by 1.5 times as compared to IGLA system);

◦         in-depth impact detonation of the missile warhead adjusting the rate of embedding to the approach speed;

◦         proximity detonation of the missile warhead (in the event of mishit) with optimization of the detonation point;

◦         detonation of the sustainer's remaining solid propellant;

◦         advanced missile accuracy characteristics.

•         extended firing range of up to 6.0 km as compared with 5.2 km for IGLA system due to missile improved aerodynamic characteristics;

•         night firing capability due to application of a night vision device holder and a light weight night vision device development.

•         easy installation on various platforms

•Unified modules are the base for:

◦         formation of "air-air" guided weapon system;

◦         formation of a mobile air defence missile system of high covertness;

◦         combination with AD gun systems;

◦         combination with medium and long range air defence systems;

◦         formation of shipborne air defence systems.



IGLA-S system is a successor of IGLA missile system family outperforming them in effectiveness, reliability, service life and survivability and retaining their best merits:

shoulder firing by a single gunner;

"fire-and-forget" concept;

high resistance to background clutter and thermal countermeasures;

easy aiming and launching;

easy maintenance and training;

high covertness of use;

retained operability in extreme operational environment.



Specification:

Range	6000 m
Target kill altitude	10-3500 m
Target velocity
in head-on	400 m/s
in tail chase	320 m/s
Combat equipment weight	max 19 kg
Missile caliber	72 mm
Missile length	1635 mm
Missile weight	11.7 kg
Warhead weight	2.5 kg
Time to transfer the system from the travelling position to combat	max 13 s
Jamming immunity	high



Universal Complex Simulator for IGLA-type MANPADS gunners

Purpose: designed to train and drill gunners of IGLA-type man-portable air defence systems (MANPADS) with simulation of the external tactical environment by means of computer graphics on a screen in a class room.



Simulator components:



pcs.

IGLA-type MANPADS and DZHIGHIT SLU combat equipment simulator

1…6*

Instructor's work station

1

Computers

5

Wide-angle tapered screen

1

Projectors

4

Audio system

1

Software (typical scenarios)

1…6*

* At the Customer's choice the simulator can be completed with any simulated combat equipment available in the set with appropriate software.

- The possibility of intensive mastering and maintaining MANPADS combat operation skills without using operational missiles and additional facilities to simulate target environment.

- much higher training rate as compared with traditional training aids due to independence of weather, time of the day and season.

- wide range of reproduced visual and audio scenarios at a launching site and target types against various background, at any season, time of the day and weather.

- objective evaluation, recording and replay of training cycles to analyze its results and identify errors in the operator's performance.

- simplicity and convenience for operation.



Specification and photos are not contractual and are subject to verification upon inspection
