1990 BOEING MD-81





TYPE:

Aircraft

DESCRIPTION:

1990 Boeing MD-81 for Sale

PRICE:

Upon Request

PACKING:

As is, where is





1990 BOEING MD-81











General Specification

Boeing MD-81


Aircraft Data

Aircraft Model:

Boeing MD-81

Date of Delivery:

1990

Engine Model:

Pratt & Whitney JT8D-200 series

Noise Compliance (Current):

Stage III





Performance Data



Operational Weight

Maximum Taxi Weight:

141,000 lb

Maximum Take-Off Weight:

140,000 lb

Maximum Landing Weight:

128,000 lb

Maximum Zero Fuel Weight:

118,000 lb





Fuel Capacity



Left Tank:

1,383 gal

Right Tank:

1,383 gal

Center Tank:

3,074 gal

Fwd Aux Tank:

N/A

Aft Aux Tank:

N/A









Airframe Status

(Data as of March 4, 2008)



Total Flight Time:

34,429:56

Total Cycle:

34,037

Time since last "C" Check (Day)

228 Days

Time since last "C" Check (FH)

1417:21 FH

Time remaining to next C Check

2182:39 FH or 228 Days (whichever comes first)





Daily Utilization (FH vs. FC):

7.0 : 7.0





Maintenance History:

Item

Accomplish Data(Flight Hour)



No.5 "C":

July 20,2007 (@33,012:35 FH)



No.4 "C":

March 28,2006 (@36,343:32 FH)



No.3 "C":

February 11,2005 (@27,712:51 FH)



No.2 "C":

December 3, 2005 (@26,146:48 FH)



Maintenance Program:

MSG 3







Maintenance Interval:

Type

Interval



A Check

450 Flight Hours



C Check

3,600 Flight Hours or 15 Months



Product Enhancement:

(a)      Insulation Blanket installed per AD2000-11-01.



(b)      Cockpit Security Door has been installed.



(c)      Modification to Class C Cargo compartment incorporated



Landing Gear Status

(Data as of March 3, 2008)



Maintenance Program:

20,000 Cycle or 10 Years





Position:

NLG

MLG-L/H

MLG-R/H

Serial Number:

R3956TU

MAL095

MAL040

Install Date:

July 16, 2007

June 30, 2000

June 30, 2000

Cycle since Last O/H:

1,276

15,236

15,236





Engine Status

(Data as of March 3, 2008)



Engine Model:

Pratt & Whitney JT8D-200 series

Takeoff Thrust sea-level rating (dry):

20,000 lb





APU Model:

Honeywell GTCP85-98DHF





Maintenance Program:

Condition Monitoring





Position:

No.1 Engine

No.2 Engine

APU

Model:

JT8D-217C

JT8D-217C

GTCP85-98DHF

Serial Number:

P725374

P725588D

P-1083

Total Time:

32,783

30,298

37,437

Total Cycle:

32,136

29,768

38,930

LSV description:

ESV2

ESV2

REPAIR

LSV date:

July 19, 2007

September 26, 2007

November 15, 2006

Time since LSV:

1,193

797

2,368

Cycle since LSV:

1,219

742

2,260

LLP Remain Cycle (First Limit):

7,597

7,634

-

HPC AD Due Date:

18 July 2019

25 September 2019





Cabin Equipment





Cabin Arrangement No.:

N01





Equipment:

Item

Manufacturer

Qty



Seats:

Tenryu Industries

Total 163 (F:0/C:0/Y:163)



Galleys:

Nordskog

3



Lavatories:

JAMCO

2













Avionics



System

Qty

Description

Vendor

Model or Part Number











Digital Flight Guidance

2

Digital Flight Guidance Computer

Honeywell

4034241-971 or -973



1

Flight Guidance Control Panel

Honeywell

4034242-934

HF System

1

(Provision only)

VHF System

2

VHF Communication Tranceiver

Collins

618M2D, 618M3 or 618M3A

Voice Recording System

1

Voice Recorder

Honeywell

965-6005-076 or -076ULD

Flight Recorder System

1

Digital Flight Data Recorder

SDC

980-4100-DXUS

Air Data Computing System

2

Digital Air Data Computer

Honeywell

HG280D80

Gyrosyn Compass System

2

Directional Gyro

Sperry

DG-206A or 2588302-4

Attitude System

2

Vertical Gyro

Honeywell

2587335-13 or -113

Marker Beacon System

1

Marker Beacon Receiver

Collins

51Z-4

VOR/ILS System

2

VOR/ILS Receiver

Collins

51RV-4

Weather Radar System

1

Weather Radar Receiver Transmitter

Bendix

RTA-4A

Radio Altimeter System

2

Radio Altimeter Tranceiver

T.R.T.

9599-607-14908

Enhanced GPWS

1

Enhanced GPW Computer

Honeywell

965-1076-020-214-214

TCAS

1

TCAS Computer

Collins

622-8971-022

Windshear Alert and Guidance System

1

Windshear Computer

Honeywell

4059845-911

DME System

2

DME Interrogator

Collins

860E-5

ADF System

2

ADF Receiver

Collins

ADF-700

ATC Transponder System

2

Mode S ATC Transponder

Collins

TPR-720

Performance Management System

1

PMS Computer Unit

Delco

7892551-011-010











Enhancement Status - AVIONICS

Compliance





EGPWS

Yes





TCAS Change 7.0

Yes





RVSM Capability

Yes





ATC mode S Transponder

Yes









Specification and photos are not contractual and are subject to verification upon inspection
